HDMI Touch Lcd Screen 10.1 Inch IPS TFT with PCB Driver Board for Wide-temp

Product Description:

The CH101WX05C-CT is a 10.1-inch TFT LCD module designed to provide a versatile display solution for various industrial and commercial applications. With a resolution of 800x1280 pixels, it offers balanced pixel density, ensuring clear and sharp graphics and text. The display utilizes IPS (In-Plane Switching) technology, enhancing color consistency and providing a wide viewing angle of 80 degrees horizontally and vertically, suitable for environments where multiple users can view the screen simultaneously without color distortion or brightness degradation.

A significant feature of the CH101WX05C-CT is its integrated 1.1mm thick glass capacitive touchscreen, powered via USB (DC 5V), supporting multi-touch for intuitive and responsive user interaction. The module uses white LED backlighting with a brightness of 300 cd/m², suitable for indoor use, balancing visibility and power consumption. The TFT dot pitch of 0.1692mm enhances the sharpness of displayed content, making it suitable for applications requiring precise visual detail, such as medical equipment, industrial control panels, and smart home interfaces.

In terms of physical design, the CH101WX05C-CT maintains a slim and lightweight profile, with an overall thickness of 4.45 mm (including PCBA and components) and dimensions of 143.4 mm wide and 228.9 mm high, facilitating integration into space-constrained devices. The module structure includes a glass sensor, SCA (spacer and cover adhesive), and a foam buffer layer; this multi-layered design enhances durability and ensures touch sensitivity over extended use.

For connectivity, the module features a 46×50×5 mm HDMI interface board, supporting high-quality video transmission from various digital sources. This interface, combined with a USB touchscreen connection, facilitates seamless integration into embedded systems, industrial equipment, and consumer electronics. The module is compatible with multiple operating systems, including Windows, Linux, macOS, and Raspberry Pi, making it suitable for embedded systems, self-service terminals, and interactive devices.

In summary, the CH101WX05C-CT is a well-balanced TFT LCD module that combines high-resolution display, sensitive capacitive touch, and flexible interfaces in a compact and durable design. It is applicable to multiple industries such as industrial automation, medical instruments, smart home control, and automotive displays, providing reliable and customizable display solutions to meet the needs of modern embedded applications.

Features:

Compact and Slim External Dimensions
The CH101WX05C-CT features a compact outline size of 143.4 mm in width and 228.9 mm in height, with a total thickness of only 4.45 mm including the PCBA and components. This slim form factor allows for easy integration into space-constrained devices, making it suitable for applications requiring lightweight and thin display modules.

High-Resolution Display
With a resolution of 800 (RGB) × 1280 pixels, the CH101WX05C-CT provides sharp and detailed images. This resolution supports clear rendering of both text and graphics, which is essential for applications such as industrial control panels and medical devices that demand precise visual output.

HDMI LCD Interface
The module is equipped with an HDMI interface board (46 mm × 50 mm × 5 mm), enabling high-quality digital video input. The HDMI interface ensures stable and fast data transmission, which is compatible with a wide range of modern devices and embedded systems, facilitating seamless integration.

Wide Viewing Angles
The display offers an 80-degree viewing angle in all directions (up, down, left, right). This wide viewing angle ensures that the screen maintains consistent color accuracy and brightness even when viewed from extreme angles, which is beneficial for multi-user environments or applications where the display is viewed from different positions.

Technical Parameters:

Support and Services:

Chenghao Optoelectronic provides comprehensive support and services for the CH101WX05C-CT display module to ensure customer satisfaction and smooth product integration. Upon purchasing the CH101WX05C-CT, customers benefit from a one-year warranty period during which any product defects or malfunctions are addressed promptly. Within 30 days of delivery, defective units can be replaced to minimize downtime and maintain operational efficiency.

Technical support is a key component of Chenghao’s service offering. Their experienced technical team is available to provide remote assistance for any issues encountered during testing or deployment of the CH101WX05C-CT module. This includes guidance on installation, troubleshooting, and optimizing the module’s performance according to specific application requirements.

Quality assurance is guaranteed through strict pre-shipment inspections and testing. The CH101WX05C-CT modules undergo rigorous quality control processes to ensure they meet industry standards and certifications such as CE and RoHS. Additionally, Chenghao can provide customers with relevant certification documents upon request, facilitating compliance with regulatory requirements.

Logistics and packaging are handled with care to protect the delicate display modules during transit. Each unit is securely packed using foam padding inside export-standard boxes, with the total weight per box controlled to avoid damage. For larger shipments, pallets or wooden frames are used to enhance protection.

Chenghao Optoelectronic’s commitment to customer satisfaction extends beyond product delivery. They maintain long-term partnerships with express logistics companies to offer competitive shipping rates and timely delivery. Customers are encouraged to contact the sales and technical teams for any inquiries or support needs related to the CH101WX05C-CT module
